Our Mission

Provide high quality, low cost single source solutions for PCB Fabrication and Assembly services for our Customers with the convenience of a One Stop Shop.

24/7 Support

24 hour support for quotes and technical help.

Fast

Quick Turn Prototypes, 24 hour turns available. Delivery in as little as 3 days for off-shore orders .

ISO certified

Domestic and overseas manufacturing for pre-production and production runs in ISO Certified facilities.

Our Services

graphic

Fabrication

Rigid PCBs up to 42 layers

.0025” trace/space

Minimum Mechanical drill size 4-mil

Via-In-Pad / microvias and laser vias

Minimum Laser drill size 3-mil

ISO-9001 and UL certified facilities

Controlled Impedance

Blind / Buried Vias / Buried Chip resistors

Commercial and MILSPEC approved

RoHS Compliant (all options available)

High temperature, high frequency material

Aluminum and other special materials

Quick turn service 24 hour turns available

Domestic and overseas fabrication to suit your needs and cost requirements

Flex and rigid flex boards

All surface finishes available (ENIG, silver, hard gold, HAL, Entek, etc)

graphic

PCB Assembly

Double sided SMT

Leaded/ Lead Free/RoHS compliant

Passive / Active Components.

Components as small as 0201

QPF, BGA & CSP

Wave/Selective Solder

AOI Inspection

X-Ray Inspection

BGA rework and repair services available

In-Circuit (Level 4) Test

Functional Test

Box builds

Component sourcing for even hard to find or obsolete parts

Cable assemblies

graphic

Material Procurement

Vast inventory of parts in our wherehouse

We have an extensive network of well established partnerships with domestic and overseas Manufacturers and Distributors

Full 24/7 support to our customers

Quick quotes (turn times as little as 1-2 days)

Partial procurement of parts on your BOM is not a problem.

BOM analysis and feedback to improve your future costs

Full traceability on all parts sold

graphic

PCB Design Service

Getting designs to the Marketplace First is critical to our customer’s success. SBC is the “World Leader" in getting your product to the market place first. To accomplish this goal we offer the quickest turns in the industry from PCB Layout to Loaded Assembly so your engineers can verify their designs right away. If you are looking to utilize our service: “Worlds Quickest” PCB Layout to Loaded Assembly you should contact us immediately.

PCB Design & Layout Capabilities

SBC can work closely with your team to design products from concept or an existing solid design framework through full production. SBC has the capability for “quick turn” or "standard basis", layouts down to as little as 24 hours, offering a wide variety of technologies including:

1. High Layer Counts
2. Mixed Technologies
3. Micro BGA Layouts – BGA’s – Fine Pitch SMD’s
4. Test Boards, Probe Cards and EVM Boards
5. High Speed Digital Boards
6. High Power and Super High Power Layouts
7. High Pin Count Layouts
8. Quick-Turn Quality Layouts
9. Differential Impedance Control
10. As a standard part of our process SBC verifies all designs for manufacturability (DFM) and testability (DFT).
11. RoHS Compliant Designs

Schematic Assistance – Typically Customers provide schematics along with the additional information required to layout a PC Board. In cases where you require assistance to build your schematic please don’t hesitate to contact us.

PCB Layout/Design Software Platforms Available

We offer a wide variety of Design/Layout Platforms including:
1. PADS (Mentor Graphics)
2. Cadence Allegro

Ordering PCB Layout Services

Information Required to Quote and Produce a Printed Circuit Board Layout: 1. Complete and verified schematic(s) in one of the software platforms we offer. (PCAD, Cadence Allegro, PADS (Mentor Graphics), or Altium Designer).
2. Complete and verified BOM. Customer must spec. out each component for the layout, based on their familiarity with requirements of the circuitry.
3. Part numbers for components must be complete, along with package/footprint details for each component.
4. Board form factors in one of the software platforms we offer. We can also work with DXF files from CAD tools (like AutoCAD, etc.).
5. Any special layout routing or fabrication requirements. Special Requirements or Non-Standard Tolerances.

Delivered to you with your PCB Layout:

1. IPC Netlist
2. Assembly Drawing(s) in pdf and/or Gerber format
3. Updated "Bill of Materials" (BOM)
4. Fabrication Drawing(s) in pdf and/or Gerber format
5. Pick & Place (PNP) Data
6. Gerber Data for all layers in RS274X format
7. Drill Data in Excellon Format
Building Your PCB Design/Layout - Taking the Next Step Once Smart MFG. has completed your PCB Layout we can manufacture and assembly boards in as little as 48 hours, right in the same facility.
